DRPS-1C-SSR-D60/D48/0.1-09Z(H)
30010000291
Ultra thin solid-state relay, transistor or MOSFE output, PCB board or base installation, load voltage 48VDC
Rated Input Voltage
- 24VDC
- 60VDC
Load Voltage Range
- 3-28VDC
- 3-58VDC
Load Current Range
- 0.1A: 0.001 - 0.1A
- 3A: 0.002 - 3A
- Overview
- Technical data
- Accessories
- Certification
- Business data
- Download
Product advantages
☑ Photoelectric isolation☑ Transistor or MOSFE output
☑ PCB board or base installation
3D model
Input Specifications
| Rated Input Voltage | DC60V |
| Input Frequency | 100Hz（with AC socket） |
| Control Voltage Range | 48-72VDC |
| Must Turn-on Voltage | 48VDC |
| Must Turn-off Voltage | 4.8VDC |
| Maximum Input Current | 15mA（@72VDC） |
Output Specifications
| Load Voltage Range | 48V: 3-58VDC |
| Maximum Transient Overvoltage | 48V: 58VDC |
| Load Current Range | 0.1A: 0.001-0.1A |
| Maximum Turn-on Time | 300µs |
| Maximum Surge Current (@10 ms) | 1A: 30A |
| Maximum Off-State Leakage Current (@Rated Load Voltage) | 100µA |
| Maximum On-State Voltage Drop (@Rated Current) | 0.1A: 1.5VDC |
General Specifications
| Minimum Insulation Resistance (@500VDC) | 1000MΩ |
| Ambient Temperature Range | -30℃～+80℃ |
| Storage Temperature Range | -30℃~+100℃ |
| Order number | 30010000291 |
| Packing unit | 50 STK |
| Minimum order quantity | 50 STK |
| Products weight (without packaging) | 4g |
